GPU rack server Gigabyte G292-Z20 - HPC/AI Server - AMD EPYC™ 7002 - 2U UP 8 x PCIe Gen4 GPUs (Microchip solution)

Hỗ trợ đến 8 slot GPU

Đạt chứng chỉ Nvidia về độ ổn định, tính năng, bảo mật và hiệu năng

Single CPU AMD Epyc 7002 series 7nm / tối đa 64 nhân / 280W TDP

8 khe RAM RDIMM / LRDIMM DDR4RAM

2 cổng LAN 1Gb/s (Intel® I350-AM2)

1 cổng dedicated management

12 ổ 3.5"/2.5" SATA hot-swappable HDD/SSD

1 khe M.2 gen 4x4

3 khe Full Height Full Length PCIe Gen4 x16

2 khe Full Height Half Length PCIe Gen4 x16

1 khe OCP 3.0 Gen4 x16 mezzanine

Aspeed® AST2500 remote management controller

2 x Nguồn 2200W chuẩn 80 PLUS Platinum

8 khe RAM RDIMM / LRDIMM DDR4

128GB / slot

3200 MT/s

2 x SFP+ 10Gb/s LAN ports (Mellanox® ConnectX-4 Lx controller) Support NCSI function

Pin-to-Pin compatible with Mellanox® 25Gb/s LAN controller

1 x 10/100/1000 management LAN

Integrated in Aspeed® AST2500, 2D Video Graphic Adapter with PCIe bus interface

2 x 2.5" Gen3 NVMe/SATA/SAS hot-swappable bays 6 x 2.5" SATA/SAS hot-swappable bays

có

Depends on SAS add-on card

Depends on SAS add-on card

8 x PCIe x16 (Gen4 x16) FHFL slots for GPUs (Microchip solution) 2 x PCIe x16 (Gen4 x16 bus) low-profile slots - Maximum limitation of GPU card: 285mm (L) x 111.5mm (W) x 39.5mm (H) - System is validated for population with a uniform GPU model - Support is not provided for mixed GPU populations - For the latest GPU cards QVL, please contact your GIGABYTE representative

- M-key - PCIe Gen3 x4 - Supports 2242/2260/2280/22110 cards

- M-key - PCIe Gen3 x2 - Supports 2242/2260/2280/22110 cards

2 x M.2 slots 1 x TPM header 4 x SlimSAS connectors 1 x Buzzer

1 x Power button with LED 1 x ID button with LED 2 x LAN activity LEDs 1 x HDD activity LED 1 x System status LED 1 x Reset button

2 x USB 3.0 1 x VGA 2 x SFP+ 1 x MLAN 1 x Power button with LED 1 x ID button with LED 1 x Reset button 1 x NMI button 1 x System status LED

Speed and bandwidth: PCIe Gen3 x4 or SATA 6Gb/s or SAS 12Gb/s

1 x TPM header with SPI interface Optional TPM2.0 kit: CTM010

Dual 2200W 80 PLUS Platinum redundant power supply
